Häfele DL6000 Digital Door Lock (SKU 912.20.581)

The DL6000 smart door lock features a modern German-standard design and supports four unlocking methods: PIN code, RFID card, Hafele Smart Living app, and mechanical key. With flexible user management, dual verification for enhanced security, and intelligent alarm systems, the DL6000 offers both convenience and top-tier safety for your home.

⚠️Safety Note Product usage instruction video Installation video Frequently Asked Questions (Q&A)

Key Features

4-in-1 Access: PIN code, RFID card, Hafele Smart Living app, mechanical key.

Dual Authentication: Combine PIN and card for added protection.

Durable Stainless Steel 304 Lock Body with sleek German design.

User Permission Management via Hafele Smart Living app.

Anti-password-peeping and intrusion alert.

Low battery warning, manual lock mode from the inside for privacy.

Technical Specifications

User Capacity: Up to 50 RFID cards and 50 PIN codes; managed via the Hafele app.

Dimensions: 70 (W) x 290 (H) x 26 (D) mm.

Material: Aluminum alloy + SUS 304 stainless steel (depends on component).

Power Supply: 4V – 6.5V (4 AA alkaline batteries).

Low Battery Alert: At 4.8V.

Emergency Power Input: 5V via Micro USB.

Operating Temperature: -30°C to +70°C.

Operating Humidity: 15% – 95% RH.

Installation Requirements

Door Thickness: 38 – 60 mm.

Backset (door frame width): ≥ 110 mm.

Door Gap: ≥ 3 mm.

Included Accessories

2 large RFID cards (85 x 54 mm).

2 small RFID tags (35 x 25 mm).

2 mechanical override keys.

Origin: China.
